NOXTITE® FKM Fluoroelastomers
NOXTITE® FKM (FPM) grades cover a large range of materials available for automotive, chemical and industrial applications with bisphenol and peroxide curable copolymers as well as terpolymers. Our broad portfolio offers elastomers with a Tg of -30°C, but also grades for service temperatures up to 250°C, all available in different viscosities
Our Fluoroelastomers surpass the industry requirements for dynamic stability, extreme heat/cold exposure, fuel resistance and aggressive engine or transmission fluids.
FKM Fluoroelastomers Selection Guide
| POLYMER PROPERTIES | |||||
| Product Name | 1ML(1+10) @ 121°C | Polymer Structure | Fluorine cont. [wt.-%] | 2Tg [°C] | Key Features |
|---|---|---|---|---|---|
| Peroxide Curable FKM Grades for best Chemical Resistance | |||||
| Dynamic Performance Grades | |||||
| NOXTITE® RE 620 | 20 | VdF | HFP | 66 | -20 | low mooney version of RE 635, best tear resistance & hose FKM, excellent extrudability, high dynamic performance, outstanding fatigue properties |
| NOXTITE® RE 635 | 30 | VdF | HFP | 66 | -20 | Best tear resistance & hose FKM, excellent extrudability, high dynamic performance, outstanding fatigue properties |
| NOXTITE® FX 6301 | 22 | VdF | HFP | 66 | -20 | Non-fluorosurfactant hose FKM, excellent extrudability, high dynamic performance, outstanding fatigue properties |
| Medium Fluorine Allround Grades | |||||
| NOXTITE® RE 461 | 35 | VdF | HFP | TFE | 68 | -18 | Standard medium fluorine FKM, easy extrudability |
| NOXTITE® RE 462 | 10 | VdF | HFP | TFE | 68 | -18 | General viscosity modifier for all FKM elastomers |
| NOXTITE® RE 463 | 40 | VdF | HFP | TFE 3D-technology |
68 | -18 | Advanced medium fluorine FKM, no post cure needed |
| NOXTITE® RE 464 | 23 | VdF | HFP | TFE | 67 | -21 | |
| Extreme Fluid Resistant High-Fluorine Grades | |||||
| NOXTITE® RE 430 | 25 | VdF | HFP | TFE 3D-technology |
>70 | -6 | Excellent dynamic properties and fuel (FAM-B) permeation resistance, well balanced heat and compression set resistance |
| NOXTITE® RE 431 | 65 | VdF | HFP | TFE 3D-technology |
>70 | -4 | |
| Low Temperature Grades | |||||
| NOXTITE® RE 556 | 52 | VdF | TFE | PMVE 3D-technology |
64 | -30 | Standard low temperature FKM |
| NOXTITE® RE 557 | 30 | VdF | TFE | PMVE 3D-technology |
64 | -30 | Easy to process low temperature FKM |
| NOXTITE® RE 558 | 10 | VdF | TFE | PMVE | 64 | -31 | Low temperature modifier for all FKM elastomers |
| Bisphenol Curable FKM Grades for highest Heat Resistance | |||||
| Common FKM Grades | |||||
| NOXTITE® RE 230 | 35 | VdF | HFP | 66 | -19 | Favorable FKM copolymer base gums |
| NOXTITE® RE 250 | 52 | VdF | HFP | 66 | -19 | |
| NOXTITE® FX 2316 | 33 | VdF | HFP | 66 | -19 | Non-fluorosurfactant FKM copolymer base gum |
| NOXTITE® RE 246 | 35 | VdF | HFP | 66 | -19 | Precompound copolymer (cure system, bonding promotor & process aids) for superior batch-to-batch consistency |
All properties provided are typical properties and not intended to serve as specifications
1) JIS K6300 method; 2)Tg is based on the polymer, DIN EN ISO 11357-2 method
VdF:Vinylidene difluoride; HFP: Hexafluoroproylene; TFE: Tetrafluoroethylene; PMVE: Perfluoro (methyl vinyl ether)
